TPU Irrigation Hose

TPU Irrigation Hose is an extruded-through-the-weave hose for water delivery, irrigation, water or slurry discharge, most durable hoses than others

Details about TPU Irrigation Hose

Features

TPU Irrigation hose layout
TPU Irrigation hose layout
  • High adhesion strength & top fatigue resistance
  • TPU liner provides  extreme chemical resistance
  • TPU cover provides Extreme abrasion resistance
  • Outstanding diameter stability
  • Lager volume transfer capability of liquid
  • Lighter, softer for easy deployments
  • Temperature range from -58°F to 158°F (-50°C to 70°C)

Technical Data

Nominal Size

Working Pressure Burst Pressure Weight Wall Thickness Tensile Strength
inch mm psi bar psi bar Lbs./ft. Kg/m inch mm Lbs.

Kg

4″

102 250 17 750 51 0.56 0.84 0.094  2.4 32640 16320

5″

127 225 15 675 47 0.74 1.11 0.10 2.5 35400 17700
5-1/2″ 140 225 15 675 47 0.83 1.24 0.102  2.6 42570

19350

6″ 152 225 15 675 47 0.92 1.37 0.102  2.6 46200

21000

8″

200

150 10 450 30 1.63 2.45 0.122  3.1 42240 19200
10″ 254 150 10 450 30 2.90 4.35 0.157  4.0 56540

25700
